Otso Voytek 2 Frame

$3,294.99

Free Shipping on Bicycle Frames within the lower 48.
Ask us for a quote for International shipments!

SKU: OTSV2FR Categories: , Tag:

The Otso Voytek 2 frame is made for year-round adventures, seamlessly transitioning from winter snow to summer trails. Made from innovative carbon fiber, its patented design features a narrow Q-factor for improved pedaling efficiency and better control, just like a traditional mountain bike.


Overview

The Otso Voytek 2 SLX is the ultimate blend of a mountain bike’s agility and a fat bike’s rugged capability. Featuring a patented, adaptable carbon frame and a streamlined Q-factor, this bike is built for comfort and responsiveness on diverse terrains.

With the innovative Tuning Chip™ system, you can easily adjust its geometry to suit any trail. The Shimano SLX 11-speed drivetrain and Magura MT4 brakes provide top-notch performance and control. Whether tackling snowy trails or hitting the dirt, the Voytek 2 SLX is designed to aexcel all year round.

Features

Tire Clearance & Wheel Swapping

The Voytek 2 offers versatile tire clearance for 26” x 4.6”, 27.5” x 4.5”, or 29” x 3.0” tires and allows easy wheel swapping to adapt to various riding conditions without compromising performance.

Suspension Correction:
The Voytek 2 is suspension corrected, allowing the use of a 120mm travel suspension fork without altering the bike’s geometry compared to a rigid fork.

Dropper Compatibility:
The Voytek 2 features internal dropper post routing through a port behind the head tube, with the Wolf Tooth Resolve Dropper Post available as an option in the Voytek 2 Custom Bike Builder.

Large Front Triangle:
The Voytek 2’s larger front triangle provides ample space for additional cargo, allowing for a custom frame bag, two bottles, or other essentials needed for your ride.

Specs

Frame Specifications

  • Material: 100% EPS molded carbon fiber
  • Design Features: Voytek™ patented carbon frame with Tuning Chip™ dropout system, 177×12 rear hub spacing, guided internal rear derailleur routing, accommodates internally routed dropper posts, external brake routing, downtube and chainstay protectors, matching alloy bottle cage bolts

Fork Specifications

  • Fork Type: Voytek™ rigid carbon fork, suspension corrected
  • Details: Tapered steerer tube, 485mm axle-to-crown, 51mm offset

Wheel Compatibility

  • Tire Clearance: Can fit wide range of tire sizes, up to 26×4.6-inch fat tires
  • Wheel Adaptability: Supports wheel swapping for different conditions and uses

Additional Features

  • Geometry: Modern MTB geometry optimized for speed and stability
  • Q-Factor: Narrow Q-factor design for efficient pedaling and improved bike handling
  • Rear Wheel Dish Offset: Features a 5mm offset rear wheel to accommodate larger tires and maintain a narrow Q-factor

Build Options

  • Headset: Cane Creek 10 Series, IS41/IS52
  • Brakes, Shifters, and Derailleur: Equipped with high-quality Shimano components

Warranty

Warranty Coverage:

  • All Otso frames are warranted against defects in materials and workmanship for 5 years from the date of retail purchase.
  • This warranty applies to the original owner only and is not transferable.
  • Please keep your sales receipt or order number for any warranty claims to ensure a quick resolution.

What’s Not Covered:

  • Damage from improper assembly, maintenance, or user/assembler inexperience.
  • Modifications, neglect, misuse, competition, commercial use, or accidents.
  • Installation of incompatible components, parts, or accessories.
  • Normal wear and tear, or damage to paint, surface finish, or aesthetics.
  • Compatibility of original components with a replacement frame is not guaranteed.
  • Costs for labor, parts removal, refitting, or re-adjustment, including wheel rebuilds.

Claim Process:

  • Warranty claims are limited to the repair or replacement of the defective frame, at Otso’s discretion.
  • This warranty does not cover incidental or consequential damages.

Legal Information:

  • This warranty gives you specific legal rights, which may vary based on location. It does not affect your statutory rights.
