Salsa Fargo GRX 610

Overview

Whether you dream of local overnighters or round-the-world epics, Fargo GRX 610 can help bring it to life. Its triple-butted steel frame and Cutthroat Carbon Deluxe fork create a comfortable-yet-durable ride that’s engineered for loaded touring on mixed terrain. Adjustable Alternator 1.0 Flat Mount dropouts let you tinker with wheelbase and ride feel, and cargo mounts galore give you the freedom to roam farther between resupplies. Shimano’s GRX 610 1 x 12 drivetrain is a smooth-shifting system with more enough gear range for climbing the Cordillera Blanca or capitalizing on tailwinds in Croatia. Fargo’s ride quality and adaptability make it a smart choice for a steel bikepacking bike — we know you’ll go far together.

Features

Triple-butted CroMoly steel frame

Alternator 1.0 Flat Mount dropouts allow for flat-mount brakes and many different drivetrains, including single speed and belt drive

Cutthroat Carbon Deluxe fork features two sets of Three-Pack mounts, lowrider rack mounts, internal dynamo cable routing, flat-mount brake mounts, and abrasion-resistant plates

Wheel size versatility: run 27.5+, 29, or 29+ wheels and tires (29 x 2.6″ max on XS frames)

Rear rack mounts (designed for use with the Salsa Alternator Standard Rack)

Fender mounts (maximum 29 x 2.2″ tire clearance with fenders)

Clearance for 29 x 3.0″ tires without fenders (29 x 2.6″ max on XS frames)

Specs

Frame measurements (mm)	XS	SM	MD	LG	XL
A. Effective Top Tube	520	540	565	590	620
B. Stand Over	690	732	778	821	859
C. Reach	350	364	368	385	409
D. Stack	594	615	643	671	690
E. Total Seat Tube Length	355.6	406.4	457.2	508.0	558.8
F. Headtube Length	90	110	140	170	190
G. Headtube Angle	68.5	69	69	69	69
H. Seat Tube Angle	74	74	73	73	73
I. BB Drop	70	70	70	70	70
J. BB Height	303	303	303	303	303
K. Chainstay Length	445–462	445–462	445–462	445–462	445–462
L. Fork Length Axle to Crown	480	480	480	480	480
M. Fork Offset	51	51	51	51	51
N. Wheelbase	1050–1067	1067–1084	1083–1100	1110–1127	1141–1158

Component measurements (mm)
Crank Arm Length	170	170	170	175	175
Handlebar Width	440	460	480	500	520
Stem Length	60	70	70	80	80

* All dimensions are preliminary and subject to change

Frameset

Frame

Fargo, Triple-butted CroMoly Steel

Fork

Cutthroat Carbon Deluxe

Drivetrain

Crankset

Shimano MT510, 34t

Bottom Bracket

Shimano BB52

Front Derailleur

N/A

Rear Derailleur

Shimano GRX RX822

Cassette / Cog

Shimano Deore M6100 HYPERGLIDE+, 10–51t, 12-speed

Chain

Shimano Deore M6100 HG

Components

Grips / Bar Tape

Anti-slip shock-proof

Handlebar

Salsa Cowchipper

Stem

Salsa Guide

Headset

FSA Orbit ITA

Shifter/Brake Levers

Shimano GRX RX610

Brakes & Rotors

Shimano GRX RX410, Shimano RT64 (Center Lock, 160 mm front and rear)

Saddle

DDK 255

Seatclamp

Salsa Lip-Lock

Seatpost

Salsa Guide

Wheels

Front Wheel

Shimano TC500-15-B, 15 x 110mm, WTB ST i25 TCS 2.0, 32h, 29″

Rear Wheel

Shimano TC500-MS-B, 12 x 148mm, WTB ST i25 TCS 2.0, 32h, 29″

Tires

Teravail Sparwood, 29 x 2.2″, 60TPI Durable casing, tubeless-ready

Tubes

included

Other

Pedals

not included

* Specifications are subject to change without notice

Warranty

SALSA CYCLES LIMITED WARRANTY

All Salsa products are warranted against manufacturing defects in materials and workmanship from the date of retail purchase of the product, subject to the limitations detailed below. Every Salsa frame, component, and apparel has a useful product life cycle. The length of that useful product life cycle will vary depending on the construction and the materials of the product, maintenance and care the product receives, and the amount and type of use the product is subjected to over its life. Your bike has an intended level of use as defined by the ASTM Riding Condition Classification Chart. Failure to adhere to the use cases identified in this chart will void your warranty. Save your dated receipt for proof of purchase. NOTE: All warranty periods below apply to original owner only

Salsa Cycles does not guarantee the compatibility of original components with a warranty replacement frame. Salsa Cycles is not responsible for parts or labor required to remove and/or refit and re-adjust the product within the bicycle assembly, including wheel rebuilds.

Salsa Cycles cannot guarantee a color match to the original frame, component, or apparel in the event of a replacement.

UNDER THREE YEAR WARRANTY

Aluminum front triangles of suspension frames
All Salsa components

UNDER TWO YEAR WARRANTY

Aluminum chainstays of suspension frames
Aluminum seatstays of suspension frames
All other suspension frame parts (excludes hanger, pivot hardware, bearings)

THIS WARRANTY DOES NOT COVER THE FOLLOWING:

Damage due to improper assembly or follow-up maintenance or lack of skill, competence or experience of the user or assemble
Bicycles that were not assembled or serviced by an authorized Salsa Cycles dealer
Products that have been modified, neglected, used in competition, or for commercial purposes such as rental, courier, police, security, etc, misused or abused, involved in accidents or anything other than normal use
Installation of components, parts, or accessories not originally intended for use with or compatible with Salsa frames and components
Salsa Cycles bicycles, frames, components or softgoods purchased from an unauthorized dealer
Salsa Cycles bicycles, frames, components or softgoods purchased from third-party internet sites, including auction websites, and regional trading websites (examples: Amazon, eBay, and Craigslist) are not covered under this warranty, even if you have a receipt
Sandblasting, sanding, grinding, wire brushing, filing, welding, brazing, drilled holes, anodizing, refinishing, powder coating, or chrome plating the bicycle, frame, or component will void the warranty
Internal rust perforation on all steel frames
Wear, scratches, chips and cracks to paint, finish, or coating on all Salsa frames and components
Bent or broken derailleur hangers or Alternator plates
Labor required to remove and/or refit and re-adjust the product within the bicycle assembly, including wheel rebuilds
Damage to carbon fiber caused by any carbon assembly paste
Normal wear and tear

LEGAL DISCLAIMER

This limited warranty is expressly limited to the repair or replacement of a defective product, at the option of Salsa Cycles, and is the sole remedy of the warranty. This limited warranty applies only to the original purchaser of the Salsa Cycles product and is not transferable. This warranty applies only to Salsa Cycles products purchased through an authorized dealer or distributor. In no event shall Salsa Cycles be liable for any loss, inconvenience or damage, whether direct, incidental, consequential, or otherwise resulting from breach of any express or implied warranty or condition of merchantability, fitness for a particular purpose, or otherwise with respect to our products except as set forth herein. This warranty gives the consumer specific legal rights, and those rights and other rights may vary from place to place. This warranty does not affect your statutory rights.

TO THE EXTENT NOT PROHIBITED BY LAW, THESE WARRANTIES ARE EXCLUSIVE AND THERE ARE NO OTHER EXPRESS OR IMPLIED WARRANTIES OR CONDITIONS INCLUDING WARRANTIES OR CONDITIONS OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.

For 2013 and older model bicycles and products, please consult your Owner’s Manual, Salsa Cycles product instructions, or contact Salsa Cycles or your authorized Salsa dealer for the applicable warranty information.
