Overview
Waveform Pedals are designed for all-mountain riding, from XC to downhill. Available in two different sizes, proportionally scaled to provide a supportive platform that’s shaped to match the footprint of your shoe. They have a slim, dual-concave profile that is 14mm thick at the perimeter and just 12.5mm thick in the center, cradling your foot for optimal pedal feel.
Each side of the pedal has 11 stainless steel rear-loading pins for loads of traction. The design also features a large, tapered leading edge to deflect pedal strikes on rough terrain. A custom radial seal protects three fully sealed cartridge bearings for low-friction riding in all conditions.
Features
- Proportionally designed platform, shaped to match shoe profile
- Slim, concave profile with large tapered leading edge to deflect pedal strikes
- 3 low friction, fully sealed cartridge bearings and 1 Igus bushing per pedal
- V-ring rotary seal to protect against contamination
- 11 stainless steel, rear-loading pins per side, includes 6 extra grip pins
- Fully serviceable with a set of hex keys, no special tools needed
Specs
- Pedal Body Material: Aluminum
- Pedal Type: Platform, Large is 112mm x 106mm, Small is 105mm x 99mm
- Pedal Spindle: 9/16″
- Spindle Material: 17-4 PH Stainless Steel
Warranty
GENERAL ONE YEAR WARRANTY
Wolf Tooth Components has a warranty on its products to be free from defects in materials or workmanship for a period of one (1) year from the original date of purchase.
TWO YEAR WARRANTY FOR RESOLVE DROPPER POST
The Wolf Tooth Resolve dropper seat post is warranted for defects in material or workmanship for a period of two years from the date of purchase. Details on the Resolve dropper seat post can be found in the user manual .
LIFETIME WARRANTY FOR PREMIUM HEADSETS
Wolf Tooth Components has a warranty on Premium Headsets to be free from defects in materials or workmanship for the lifetime of the original purchaser. Performance Headsets have a one year warranty with the same terms.
WARRANTY LIMITATIONS
Any Wolf Tooth Components product that is found to be defective in materials or workmanship will be repaired or replaced at the sole discretion of Wolf Tooth Components provided it is returned to the factory freight prepaid. This warranty does not cover damage or failure resulting from misuse, abuse, alteration, neglect, normal and reasonable wear and tear, crash or impact, failure to perform routine maintenance as instructed, or use other than that for which the product was intended.
If a defect is found, our entire liability and your sole remedy shall be, at our option, free repair or replacement of the Wolf Tooth Components product. Wolf Tooth Components shall not be held liable for any indirect, special, or consequential damages. This written express warranty is in lieu of all other warranties, implied or expressed, and does not cover any representation or warranty made by dealers beyond the provisions of this warranty. For Warranty Issues, please contact us using our Warranty Request Form.
